QD48XH300, Timing Pulley

QD48XH300 - Cast Iron Imperial Pitch Pulleys

QD48XH300

QD48XH300, Timing Pulley, Cast Iron, Black Oxide,

Learn more about QD48XH300 Timing Pulleys and Toronto Gear Works. Compare product dimensions, download a CAD file, or buy online.

Specifications

Product Number QD48XH300
Teeth 48
Tooth Style XH
For Belt Width (in) 3.0000
Type D-2
Material Cast Iron
Finish Black Oxide
Bore Type QD
Bore Description Bored for F Bushing
Pitch Diameter (in) 13.369
Outside Diameter (in) 13.259
Face Width (in) 3.625
Overall Length (in) 4.906
Min. Bore (in) 1
Unit System Inch
Bushing F
P.D. (mm) 340.00
O.D. (mm) 336.80
MOQ 1
Weight (lb) 43.62
Part Number Cross Reference 48XH300F, 48XH300-F, 20182113, 48XH300, 48XH300QD, 48XH300-F, P48XH300 F, 48XH300F, Q48XH300, QD48XH300, QD48XH300

Comparable to: 48XH300F, 48XH300-F, 20182113, 48XH300, 48XH300QD, 48XH300-F, P48XH300 F, 48XH300F, Q48XH300, QD48XH300, QD48XH300
