90-8P50-3020, Timing Pulley

90-8P50-3020 - Cast Iron Powerhouse® Pulleys

90-8P50-3020

90-8P50-3020, Timing Pulley, Cast Iron, Black Oxide,

Learn more about 90-8P50-3020 Timing Pulleys and Toronto Gear Works. Compare product dimensions, download a CAD file, or buy online.

Specifications

Product Number	90-8P50-3020
Teeth	90
Tooth Style	8P
For Belt Width (mm)	50.00
Type	A-1
Material	Ductile Iron
Finish	Black Oxide
Bore Type	TL
Bore Description	Bored for 3020 Bushing
Pitch Diameter (in)	9.023
Outside Diameter (in)	8.969
Face Width (in)	2.380
Overall Length (in)	2.380
Min. Bore (in)	0.875
Pulley Belt Width (in)	2.140
Unit System	Inch
Bushing	3020
P.D. (mm)	229.00
O.D. (mm)	227.80
MOQ	1
Weight (lb)	28.62
Part Number Cross Reference	P90-8MGT-50, B908M50TL, P90-8M-50-3020, 20182881, P90-8M-50-3020 HT250 SPKT, P908M50TL, 90-8P50-3020, 112898, 90-8P50-3020

Comparable to: P90-8MGT-50, B908M50TL, P90-8M-50-3020, 20182881, P90-8M-50-3020 HT250 SPKT, P908M50TL, 90-8P50-3020, 112898, 90-8P50-3020
