40LH050, Timing Pulley, Cast Iron
Specifications
| Product Number | 40LH050 |
| Teeth | 40 |
| Tooth Style | L |
| For Belt Width (in) | 0.500 |
| Type | 5 |
| Material | Ductile Iron |
| Flange Material | Steel |
| Bore Type | Split Taper |
| Bore (in) | H |
| Pitch Diameter (in) | 4.775 |
| Outside Diameter (in) | 4.745 |
| Flange Diameter (in) | 5.000 |
| Face Width (in) | 0.750 |
| Overall Length (in) | 1.438 |
| Min. Bore (in) | 0.375 |
| Unit System | Inch |
| Bushing | H |
| MOQ | 1 |
| Weight (lb) | 3.04 |
| Part Number Cross Reference | 1056084, 40LH050 |
