40HQ200, Timing Pulley, Cast Iron
Specifications
| Product Number | 40HQ200 |
| Teeth | 40 |
| Tooth Style | H |
| For Belt Width (in) | 2.000 |
| Type | E1F |
| Material | Ductile Iron |
| Flange Material | Steel |
| Bore Type | Split Taper |
| Bore (in) | Q1 |
| Pitch Diameter (in) | 6.386 |
| Outside Diameter (in) | 6.312 |
| Flange Diameter (in) | 6.563 |
| Face Width (in) | 2.500 |
| Overall Length (in) | 2.781 |
| Min. Bore (in) | 0.750 |
| Unit System | Inch |
| Bushing | Q1 |
| MOQ | 1 |
| Weight (lb) | 12.95 |
| Part Number Cross Reference | 1057371, 40HQ200 |
