40B8, Roller Chain Sprocket, Steel
Specifications
| Product Number | 40B8 |
| Teeth | 8 |
| Tooth Style | 40 |
| Type | B |
| Material | Steel |
| Bore Type | Minimum Plain Bore |
| Bore (in) | 1/2 Inch Minimum Plain Bore |
| Pitch Diameter (in) | 1.307 |
| Outside Diameter (in) | 1.507 |
| Face Width (in) | 0.284 |
| Overall Length (in) | 0.875 |
| Hub Diameter (in) | 0.969 |
| Min. Bore (in) | 0.500 |
| Unit System | Inch |
| MOQ | 1 |
| Weight (lb) | 0.10 |
| Part Number Cross Reference | 40B8, 40B72 |
