40B51, Roller Chain Sprocket, Steel
Specifications
| Product Number | 40B51 |
| Teeth | 51 |
| Tooth Style | 40 |
| Type | B |
| Material | Steel |
| Bore Type | Minimum Plain Bore |
| Bore (in) | 3/4 Inch Minimum Plain Bore |
| Pitch Diameter (in) | 8.122 |
| Outside Diameter (in) | 8.407 |
| Face Width (in) | 0.284 |
| Overall Length (in) | 1.125 |
| Hub Diameter (in) | 3.500 |
| Min. Bore (in) | 0.750 |
| Unit System | Inch |
| MOQ | 1 |
| Weight (lb) | 5.32 |
| Part Number Cross Reference | 40B51 |
