28XL037M6A8, Timing Pulley

28XL037M6A8 - Aluminum Metric Pulleys

28XL037M6A8

28XL037M6A8, Timing Pulley, Aluminum, Clear Anodized,

Learn more about 28XL037M6A8 Timing Pulleys and Toronto Gear Works. Compare product dimensions, download a CAD file, or buy online.

Specifications

Product Number 28XL037M6A8
Teeth 28
Tooth Style XL
For Belt Width (in) 0.3750
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore Description 8 mm Finished Bore
Bore (mm) 8.00
Pitch Diameter (in) 1.783
Outside Diameter (in) 1.763
Pulley Belt Width (mm) 9.50
Unit System Metric
P.D. (mm) 45.00
O.D. (mm) 44.80
Face Width (mm) 23.80
Overall Length (mm) 9.50
Hub Diameter (mm) 32.00
MOQ 1
Weight (lb) 0.20
Part Number Cross Reference A 6A3M28NF09508, A6A3M28NF09508, 28XL037M6A8, 28XL037M6A8
Set Screw Quantity 2
