20LT187-6A3, Timing Pulley

20LT187-6A3 - Aluminum Imperial Pitch Pulleys

20LT187-6A3

20LT187-6A3, Timing Pulley, Aluminum, Clear Anodized

Learn more about 20LT187-6A3 Timing Pulleys and Toronto Gear Works. Compare product dimensions, download a CAD file, or buy online.

Specifications

Product Number	20LT187-6A3
Teeth	20
Tooth Style	LT
For Belt Width (in)	0.1875
Type	6
Material	Aluminum
Finish	Clear Anodized
Bore Type	Finished Bore
Bore (in)	0.250
Bore Description	1/4 Inch Finished Bore
Pitch Diameter (in)	0.519
Outside Diameter (in)	0.499
Face Width (in)	0.750
Overall Length (in)	0.436
Hub Diameter (in)	0.436
Min. Bore (in)	0.25
Unit System	Inch
P.D. (mm)	13.00
O.D. (mm)	12.70
MOQ	1
Weight (lb)	0.02
Part Number Cross Reference	A 6A6-20NF01808, A6A6-20NF01808, 20LT-187 X 1/4-6, 20M187-2A X 1/4, 20LT187-6A3, 20LT187-6A3
Set Screw Quantity	2

Comparable to: A 6A6-20NF01808, A6A6-20NF01808, 20LT-187 X 1/4-6, 20M187-2A X 1/4, 20LT187-6A3, 20LT187-6A3

Documentation

Download Catalog

General Characteristics

Pulley Tolerances

Part Number Nomenclature Chart

Drive Alignment Guide

For custom parts click here

RoHS Certification
