19-5M09M6A8, Timing Pulley

19-5M09M6A8 - Aluminum Powerhouse®HTD® Pulleys

19-5M09M6A8

19-5M09M6A8, Timing Pulley, Aluminum, Clear Anodized

Learn more about 19-5M09M6A8 Timing Pulleys and Toronto Gear Works. Compare product dimensions, download a CAD file, or buy online.

Specifications

Product Number 19-5M09M6A8
Teeth 19
Tooth Style HTD5mm
For Belt Width (mm) 9.00
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore Description 8 mm Finished Bore
Bore (mm) 8.00
Pitch Diameter (in) 1.191
Outside Diameter (in) 1.146
Pulley Belt Width (mm) 9.00
Unit System Metric
P.D. (mm) 30.00
O.D. (mm) 29.10
Face Width (mm) 13.90
Overall Length (mm) 20.20
Hub Diameter (mm) 19.10
MOQ 1
Weight (lb) 0.10
Part Number Cross Reference A 6A25M019NF0908, A6A25M019NF0908, 19-5M09M6A8, 19-5M09M6A8
Set Screw Quantity 2
