18XL037M6A8, Timing Pulley

18XL037M6A8 - Aluminum Metric Pulleys

18XL037M6A8

18XL037M6A8, Timing Pulley, Aluminum, Clear Anodized

Learn more about 18XL037M6A8 Timing Pulleys and Toronto Gear Works. Compare product dimensions, download a CAD file, or buy online.

Specifications

Product Number 18XL037M6A8
Teeth 18
Tooth Style XL
For Belt Width (in) 0.3750
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore Description 8 mm Finished Bore
Bore (mm) 8.00
Pitch Diameter (in) 1.146
Outside Diameter (in) 1.126
Pulley Belt Width (mm) 9.50
Unit System Metric
P.D. (mm) 29.00
O.D. (mm) 28.60
Face Width (mm) 22.20
Overall Length (mm) 9.50
Hub Diameter (mm) 22.00
MOQ 1
Weight (lb) 0.10
Part Number Cross Reference A 6A3M18NF09508, A6A3M18NF09508, 18XL037M6A8, 18XL037M6A8
Set Screw Quantity 2
