18-3M09M6A6, Timing Pulley

18-3M09M6A6 - Aluminum Powerhouse®HTD® Pulleys

18-3M09M6A6

18-3M09M6A6, Timing Pulley, Aluminum, Clear Anodized

Learn more about 18-3M09M6A6 Timing Pulleys and Toronto Gear Works. Compare product dimensions, download a CAD file, or buy online.

Specifications

Product Number 18-3M09M6A6
Teeth 18
Tooth Style HTD3mm
For Belt Width (mm) 9.00
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore Description 6 mm Finished Bore
Bore (mm) 6.00
Pitch Diameter (in) 0.677
Outside Diameter (in) 0.647
Pulley Belt Width (mm) 9.00
Unit System Metric
P.D. (mm) 17.00
O.D. (mm) 16.40
Face Width (mm) 12.80
Overall Length (mm) 20.60
Hub Diameter (mm) 11.20
MOQ 1
Weight (lb) 0.02
Part Number Cross Reference A 6A23M018NF0906, A6A23M018NF0906, 18-3M09M6A6, 18-3M09M6A6
Set Screw Quantity 2
