16XL037M6A8 Imperial Pitch Pulleys

16XL037M6A8 - Aluminum Metric Pulleys

Product Details for 16XL037M6A8

Comparable to: A AMNF, A6A3M15NF09508

16XL037M6A8, Timing Pulley, Aluminum, Clear Anodized

Specifications

Product Number 16XL037M6A8
Teeth 16
Tooth Style XL
For Belt Width (in) 0.375
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore (mm) 8.00
Set Screw 2 x M4 @ 90°
Pulley Belt Width (mm) 9.50
Unit System Inch
P.D. (mm) 25.90
O.D. (mm) 25.40
Face Width (mm) 22.20
Overall Length (mm) 9.50
Hub Diameter (mm) 19.00
MOQ 1
Weight (lb) 0.08
Part Number Cross Reference A AMNF, A6A3M15NF09508
Set Screw Quantity 2
