16-3M06-IA2 Powerhouse® HTD® Pulleys
16-3M06-IA2, Timing Pulley, Aluminum, Clear Anodized
Specifications
| Product Number | 16-3M06-IA2 |
| Teeth | 16 |
| Tooth Style | HTD 3mm |
| For Belt Width (mm) | 6 |
| Type | 6FI |
| Material | Aluminum |
| Finish | Clear Anodized |
| Bore Type | Finished Bore |
| Bore (in) | 3/16 Inch Finished Bore |
| Pitch Diameter (in) | 0.602 |
| Outside Diameter (in) | 0.572 |
| Flange Diameter (in) | 0.710 |
| Face Width (in) | 0.386 |
| Overall Length (in) | 0.563 |
| Hub Diameter (in) | 0.625 |
| Min. Bore (in) | 0.1875 |
| Unit System | Inch |
| Number & Screw Size | 1 x 2-56 |
| MOQ | 1 |
| Weight (lb) | 0.01 |
| Part Number Cross Reference | A 6D23-016DF0606, A6D23-016DF0606 |
| Set Screw Quantity | 1 |
