15XL025-6FA3 Imperial Pitch Pulleys

15XL025-6FA3 - Aluminum Imperial Pitch Pulleys

Product Details for 15XL025-6FA3

Comparable to: A 6A3-15DF02508, A6A3-15DF02508, PB15XL025, 78231505, PT015D08L04T, TP20A4W4-15, 15XL025-1A X 1/4

15XL025-6FA3, Timing Pulley, Aluminum, Clear Anodized

Specifications

Product Number 15XL025-6FA3
Teeth 15
Tooth Style XL
For Belt Width (in) 0.250
Type 6F
Material Aluminum
Finish Clear Anodized
Flange Material Aluminum
Bore Type Finished Bore
Bore (in) 1/4 Inch Finished Bore
Pitch Diameter (in) 0.955
Outside Diameter (in) 0.935
Flange Diameter (in) 1.188
Face Width (in) 0.438
Overall Length (in) 0.688
Hub Diameter (in) 0.625
Min. Bore (in) 0.250
Pulley Belt Width (in) 0.310
Unit System Inch
MOQ 1
Weight (lb) 0.04
Part Number Cross Reference A 6A3-15DF02508, A6A3-15DF02508, PB15XL025, 78231505, PT015D08L04T, TP20A4W4-15, 15XL025-1A X 1/4
Set Screw Quantity 2
