15-3M06MIA5, Timing Pulley

15-3M06MIA5 - E-Z Lock Hub Aluminum Powerhouse®HTD® Pulleys

15-3M06MIA5

15-3M06MIA5, Timing Pulley, Aluminum, Clear Anodized

Learn more about 15-3M06MIA5 Timing Pulleys and Toronto Gear Works. Compare product dimensions, download a CAD file, or buy online.

Specifications

Product Number 15-3M06MIA5
Teeth 15
Tooth Style HTD3mm
For Belt Width (mm) 6.00
Type 6FI
Material Aluminum
Finish Clear Anodized
Bore Type EZ Lock
Bore Description 5 mm Finished Bore
Bore (mm) 5.00
Pitch Diameter (in) 0.564
Outside Diameter (in) 0.534
Face Width (in) 0.334
Unit System Metric
P.D. (mm) 14.00
O.D. (mm) 13.60
Flange Diameter (mm) 17.40
Face Width (mm) 9.80
Overall Length (mm) 14.50
Hub Diameter (mm) 15.90
Number & Screw Size 1 x M2
MOQ 1
Weight (lb) 0.02
Part Number Cross Reference 15-3M06MIA5, 15-3M06MIA5
