140-14MX90-5040, Timing Pulley

140-14MX90-5040

140-14MX90-5040, Timing Pulley, Cast Iron, Black Oxide

Learn more about 140-14MX90-5040 Timing Pulleys and Toronto Gear Works. Compare product dimensions, download a CAD file, or buy online.

Product Number	140-14MX90-5040
Teeth	140
Tooth Style	14MX
For Belt Width (mm)	90.00
Type	D-3
Material	Cast Iron
Finish	Black Oxide
Bore Type	TL
Bore Description	Bored for 4535 Bushing
Pitch Diameter (in)	24.562
Outside Diameter (in)	24.452
Face Width (in)	4.203
Overall Length (in)	4.203
Min. Bore (in)	1.9375
Unit System	Inch
Bushing	5040
P.D. (mm)	624.00
O.D. (mm)	621.10
MOQ	1
Weight (lb)	245.00
Part Number Cross Reference	14MX-140S-90, 14MX140S90-5040, B14MCS-140-90, 140G-14M-90-5040, 21047857, 14MX-140S-90-5040 HT500 SPKT, 14MPC140S90, 14MX140S90-5040, 140-14MX90-5040, 482161, 140-14MX90-5040
