12XL037M6A6 Metric Pulleys

12XL037M6A6, A 6A3M12NF09506

Product Details for 12XL037M6A6

Comparable to: 12XL037M6A6, A 6A3M12NF09506,

12XL037M6A6, Timing Pulley, Powerhouse Timing, 6 mm Bore, Aluminum

Specifications

Product Number 12XL037M6A6
Teeth 12
Tooth Style XL
For Belt Width (in) 0.375
Type 6
Material Aluminum
Finish Clear Anodized
Flange Material Aluminum
Bore Type Finished Bore
Bore (mm) 6.00
Set Screw 2 x M3 @ 90°
Pulley Belt Width (mm) 9.50
Unit System Inch
P.D. (mm) 19.40
O.D. (mm) 18.90
Face Width (mm) 20.60
Overall Length (mm) 9.50
Hub Diameter (mm) 14.00
Weight (lb) 0.04
List Price (1-9 Qty.) (CAD) 11.79
Discount Price (10-24 Qty.) (CAD) 10.61
Discount Price (25-49 Qty.) (CAD) 8.26
Discount Price (50-99 Qty.) (CAD) 6.78
Discount Price (100-249 Qty.) (CAD) 5.9
Part Number Cross Reference 12XL037M6A6, A 6A3M12NF09506,

Documentation

Download Catalog 2015_TGW_CATALOG_29.pdf
General Characteristics gen_char.html
Pulley Tolerances pulley_tol.html
Part Number Nomenclature Chart part_number_explain.pdf
Drive Alignment Guide proper alignment.pdf
For custom parts click here custom.html
