12XL037-6A2 Imperial Pitch Pulleys

12XL037-6A2, A 6A3-12NF03706, PT012D06L06N

Product Details for 12XL037-6A2

Comparable to: 12XL037-6A2, A 6A3-12NF03706, PT012D06L06N

12XL037-6A2, Timing Pulley, Powerhouse Timing, 3/16 Inch Bore, Aluminum

Specifications

Product Number 12XL037-6A2
Teeth 12
Tooth Style XL
For Belt Width (in) 0.375
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore (in) 0.188
Pitch Diameter (in) 0.764
Outside Diameter (in) 0.744
Face Width (in) 0.563
Overall Length (in) 0.812
Hub Diameter (in) 0.563
Set Screw 2 x 6-40 @ 90°
Min. Bore (in) 0.188
Unit System Inch
Weight (lb) 0.03
List Price (1-9 Qty.) (CAD) 11.79
Discount Price (10-24 Qty.) (CAD) 10.61
Discount Price (25-49 Qty.) (CAD) 8.26
Discount Price (50-99 Qty.) (CAD) 6.78
Discount Price (100-249 Qty.) (CAD) 5.9
Part Number Cross Reference 12XL037-6A2, A 6A3-12NF03706, PT012D06L06N

Documentation

Download Catalog 2015_TGW_CATALOG_21.pdf
General Characteristics gen_char.html
Pulley Tolerances pulley_tol.html
Part Number Nomenclature Chart part_number_explain.pdf
Drive Alignment Guide proper alignment.pdf
For custom parts click here custom.html
