126-14MX20-3525, Timing Pulley

126-14MX20-3525 - Cast Iron Powerhouse® MX Pulleys

126-14MX20-3525

126-14MX20-3525, Timing Pulley, Cast Iron, Black Oxide

Learn more about 126-14MX20-3525 Timing Pulleys and Toronto Gear Works. Compare product dimensions, download a CAD file, or buy online.

Specifications

Product Number 126-14MX20-3525
Teeth 126
Tooth Style 14MX
For Belt Width (mm) 20.00
Type C-3
Material Cast Iron
Finish Black Oxide
Bore Type TL
Bore Description Bored for 3525 Bushing
Pitch Diameter (in) 22.106
Outside Diameter (in) 21.996
Face Width (in) 1.359
Overall Length (in) 2.500
Min. Bore (in) 1.5
Unit System Inch
Bushing 3525
P.D. (mm) 562.00
O.D. (mm) 558.70
MOQ 1
Weight (lb) 70.00
Part Number Cross Reference 14MX-126S-20, B14MCS-126-20, 126G-14M-20-3525, 20839880, 14MX-126S-20-3525 HT500 SPKT, 126-14MX20-3525, 482044, 126-14MX20-3525

Related Products

Comparable to: 14MX-126S-20, B14MCS-126-20, 126G-14M-20-3525, 20839880, 14MX-126S-20-3525 HT500 SPKT, 126-14MX20-3525, 482044, 126-14MX20-3525
