120XHS400, Timing Pulley

120XHS400 - Cast Iron Imperial Pitch Pulleys

120XHS400

120XHS400, Timing Pulley, Cast Iron

Learn more about 120XHS400 Timing Pulleys and Toronto Gear Works. Compare product dimensions, download a CAD file, or buy online.

Specifications

Product Number 120XHS400
Teeth 120
Tooth Style XH
For Belt Width (in) 4.0000
Type 14
Material Cast Iron
Bore Type Split Taper
Bore Description Bored for S1 Bushing
Pitch Diameter (in) 33.423
Outside Diameter (in) 33.313
Face Width (in) 4.688
Overall Length (in) 5.438
Min. Bore (in) 1.5625
Unit System Inch
Bushing S1
P.D. (mm) 849.00
O.D. (mm) 846.10
MOQ 1
Weight (lb) 143.00
Part Number Cross Reference 120XHS400, 120XHS400, 120XHS400
