120XHR200, Timing Pulley

120XHR200 - Cast Iron Imperial Pitch Pulleys

120XHR200

120XHR200, Timing Pulley, Cast Iron

Learn more about 120XHR200 Timing Pulleys and Toronto Gear Works. Compare product dimensions, download a CAD file, or buy online.

Specifications

Product Number 120XHR200
Teeth 120
Tooth Style XH
For Belt Width (in) 2.0000
Type 14
Material Cast Iron
Bore Type Split Taper
Bore Description Bored for R1 Bushing
Pitch Diameter (in) 33.423
Outside Diameter (in) 33.313
Face Width (in) 2.563
Overall Length (in) 3.438
Min. Bore (in) 1.125
Unit System Inch
Bushing R1
P.D. (mm) 849.00
O.D. (mm) 846.10
MOQ 1
Weight (lb) 78.50
Part Number Cross Reference 120XHR200, 120XHR200-R1, 21070744, 120XHR200, 120XHR200
