120HR300, Timing Pulley

120HR300 - Cast Iron Imperial Pitch Pulleys

120HR300

120HR300, Timing Pulley, Cast Iron

Learn more about 120HR300 Timing Pulleys and Toronto Gear Works. Compare product dimensions, download a CAD file, or buy online.

Specifications

Product Number 120HR300
Teeth 120
Tooth Style H
For Belt Width (in) 3.0000
Type 14
Material Cast Iron
Bore Type Split Taper
Bore Description Bored for R1 Bushing
Pitch Diameter (in) 19.099
Outside Diameter (in) 19.045
Face Width (in) 3.313
Overall Length (in) 3.813
Min. Bore (in) 1.125
Unit System Inch
Bushing R1
P.D. (mm) 485.00
O.D. (mm) 483.70
MOQ 1
Weight (lb) 44.20
Part Number Cross Reference 120HR300, 120HR300, 120HR300
