11XL037-6A2, Timing Pulley

11XL037-6A2 - Aluminum Imperial Pitch Pulleys

11XL037-6A2

11XL037-6A2, Timing Pulley, Aluminum, Clear Anodized

Learn more about 11XL037-6A2 Timing Pulleys and Toronto Gear Works. Compare product dimensions, download a CAD file, or buy online.

Specifications

Product Number 11XL037-6A2
Teeth 11
Tooth Style XL
For Belt Width (in) 0.3750
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore (in) 0.188
Bore Description 3/16 Inch Finished Bore
Pitch Diameter (in) 0.700
Outside Diameter (in) 0.680
Flange Diameter (in) 0.938
Face Width (in) 0.563
Overall Length (in) 0.812
Hub Diameter (in) 0.500
Min. Bore (in) 0.1875
Unit System Inch
P.D. (mm) 18.00
O.D. (mm) 17.30
MOQ 1
Weight (lb) 0.02
Part Number Cross Reference A 6A3-11NF03706, A6A3-11NF03706, 11XL037 X 3/16 6A, PT011D06L06N, 11XL037-2A X 3/16, 11XL037-6A2, 11XL037-6A2
Set Screw Quantity 1

Comparable to: A 6A3-11NF03706, A6A3-11NF03706, 11XL037 X 3/16 6A, PT011D06L06N, 11XL037-2A X 3/16, 11XL037-6A2, 11XL037-6A2

Documentation

Download Catalog
General Characteristics
Pulley Tolerances
Part Number Nomenclature Chart
Drive Alignment Guide
For custom parts click here
RoHS Certification
