112-8P50-3020 Powerhouse™ Pulleys
112-8P50-3020, Timing Pulley, Powerhouse, 3020 Bushing, Cast Iron
Specifications
| Product Number | 112-8P50-3020 |
| Teeth | 112 |
| Tooth Style | GT 8mm |
| For Belt Width (mm) | 50.000 |
| Type | A2 |
| Material | Cast Iron |
| Finish | Black Oxide |
| Bore Type | TL |
| Bore (in) | 3020 |
| Pitch Diameter (in) | 11.229 |
| Outside Diameter (in) | 11.175 |
| Face Width (in) | 2.380 |
| Overall Length (in) | 2.380 |
| Unit System | Inch |
| Bushing | 3020 |
| Weight (lb) | 35.52 |
| Part Number Cross Reference | 112-8P50-3020, P112-8MGT-50, B1128M50TL, P112-8M-50-3020, 201827 |
Documentation
| Download Catalog | 2015_TGW_CATALOG_143.pdf |
| General Characteristics | gen_char.html |
| Pulley Tolerances | pulley_tol.html |
| Part Number Nomenclature Chart | part_number_explain.pdf |
| Keyway Standards and Tolerances | keyway_specs.pdf |
| Drive Alignment Guide | proper alignment.pdf |
| For custom parts click here | custom.html |
